Closed-loop stepping drive products adopt the latest motor-specific DSP chip and closed-loop control technology to completely overcome the step loss problem of open-loop stepping motors, which can not only significantly improve high-speed performance and

2-phases stepper servo motor

  • Closed-loop stepping drive products adopt the latest motor-specific DSP chip and closed-loop control technology to completely overcome the step loss problem of open-loop stepping motors, which can not only significantly improve high-speed performance and


42 base

产品型号 Mirostep
(deg)
Length of motor
(mm)
Diameter of Shaft
(mm)
Rated current
(A)
Holding torque
(N.m)
Rotor inertia
(g.cm²)
Encoder type Match driver
42J1848EC-1000-LS-SCG 1.8 99.5 5 1.2 0.48 77 1000 2HSS57-SC
42J1860EC-1000-LS-SCG 1.8 111.5 5 2.0 0.68 110 1000 2HSS57-SC

57 base

产品型号 Mirostep
(deg)
Length of motor
(mm)
Diameter of Shaft
(mm)
Rated current
(A)
Holding torque
(N.m)
Rotor inertia
(g.cm²)
Encoder type Match driver
57J1854EC-1000-LS-SCG 1.8 113 8 4.0 1.2 280 1000 2HSS57-SC
57J1880EC-1000-LS-SCG 1.8 133.5 8 5.0 2 480 1000 2HSS57-SC

60 base

产品型号 Mirostep
(deg)
Length of motor
(mm)
Diameter of Shaft
(mm)
Rated current
(A)
Holding torque
(N.m)
Rotor inertia
(g.cm²)
Encoder type Match driver
60J1887EC-1000-LS-SCG 1.8 142.5 8 5.0 3 690 1000 2HSS57-SC
60J18100EC-1000-LS-SCG 1.8 157 8 5.0 3.5 1200 1000 2HSS57-SC

86 base

产品型号 Mirostep
(deg)
Length of motor
(mm)
Diameter of Shaft
(mm)
Rated current
(A)
Holding torque
(N.m)
Rotor inertia
(g.cm²)
Encoder type Match driver
86J1880EC-1000-LS-SCG 1.8 142 14 6.0 4.5 1800 1000 3HSS2206-SC
86J18118EC-1000-LS-SCG 1.8 175 14 6.0 8.5 2700 1000 3HSS2206-SC
86J18156EC-1000-LS-SCG 1.8 216.5 14 6.0 12.2 4000 1000 3HSS2206-SC
