External drive screw motor
The externally driven trapezoidal screw linear stepper motor has the characteristics of small size, high performance, long durability, low noise and high efficiency. At the same time, it provides a variety of body thicknesses, a variety of screw leads and
20 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
20SE1838-405-TR3.5*xxxx-01 | 38 | 1.8 | 0.5 | 0.025 | 3.5 | 0.6096 1.2192 1 2 |
0.003048 0.006096 0.01 0.02 |
28 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
28SE1832-410-TR4.77*xxxx-100-01 | 32 | 1.8 | 1.0 | 0.05 | 4.77 | 0.635 1.27 2.54 5.08 |
0.003175 0.00635 0.0127 0.0254 |
28SE1840-410-TR4.77*xxxx-100-01 | 40 | 1.8 | 1.0 | 0.08 | 4.77 | 0.635 1.27 2.54 5.08 |
0.003175 0.00635 0.0127 0.0254 |
35 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
35SE1834-415-TR6.35*xxxx-100-01 | 34 | 1.8 | 1.5 | 0.14 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
35SE1847-415-TR6.35*xxxx-100-01 | 47 | 1.8 | 1.5 | 0.2 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
42 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
42SE1834-415-TR6.35*xxxx-100-01 | 34 | 1.8 | 1.5 | 0.3 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
42SE1834-415-TR8*xxxx-100-01 | 34 | 1.8 | 1.5 | 0.3 | 8 | 1 2 4 8 10 |
0.005 0.01 0.02 0.04 0.05 |
42SE1840-415-TR6.35*xxxx-100-01 | 40 | 1.8 | 1.5 | 0.35 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
42SE1840-415*TR8*xxxx-100-01 | 40 | 1.8 | 1.5 | 0.35 | 8 | 1 2 4 8 10 |
0.005 0.01 0.02 0.04 0.05 |
42SE1848-425-TR6.35*xxxx-100-01 | 48 | 1.8 | 2.5 | 0.5 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
42SE1848-425-TR8*xxxx-100-01 | 48 | 1.8 | 2.5 | 0.5 | 8 | 1 2 4 8 10 |
0.005 0.01 0.02 0.04 0.05 |
42SE1860-425-TR6.35*xxxx-100-01 | 60 | 1.8 | 2.5 | 0.7 | 6.35 | 1.27 2.54 3.175 5.08 6.35 8.458 12.7 |
0.00635 0.0127 0.015875 0.0254 0.03175 0.04229 0.0635 |
42SE1860-425-TR8*xxxx-100-01 | 60 | 1.8 | 2.5 | 0.7 | 8 | 1 2 4 8 10 |
0.005 0.01 0.02 0.04 0.05 |
57 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
57SE1845-430-TR9.525*xxxx-150-01 | 45 | 1.8 | 3.0 | 0.7 | 6.35 | 0.635 1.27 1.5875 2.116 2.54 3.175 4.232 5.08 9.525 10.16 25.4 |
0.003175 0.00635 0.0079375 0.010508 0.0127 0.015875 0.02116 0.0254 0.047625 0.0508 0.127 |
57SE1855-430-TR9.525*xxxx-150-01 | 55 | 1.8 | 3.0 | 1.0 | 9.525 | 0.635 1.27 1.5875 2.116 2.54 3.175 4.232 5.08 9.525 10.16 25.4 |
0.003175 0.00635 0.0079375 0.010508 0.0127 0.015875 0.02116 0.0254 0.047625 0.0508 0.127 |
57SE1865-440-TR9.525*xxxx-150-01 | 65 | 1.8 | 4.0 | 1.5 | 9.525 | 0.635 1.27 1.5875 2.116 2.54 3.175 4.232 5.08 9.525 10.16 25.4 |
0.003175 0.00635 0.0079375 0.010508 0.0127 0.015875 0.02116 0.0254 0.047625 0.0508 0.127 |
57SE1876-440-TR9.525*xxxx-150-01 | 76 | 1.8 | 4.0 | 1.8 | 9.525 | 0.635 1.27 1.5875 2.116 2.54 3.175 4.232 5.08 9.525 10.16 25.4 |
0.003175 0.00635 0.0079375 0.010508 0.0127 0.015875 0.02116 0.0254 0.047625 0.0508 0.127 |
86 base
产品型号 | Length of motor (mm) |
Microstep (deg) |
Rated Current (A) |
Holding torque (N.m) |
Screw Diameter (mm) |
Screw lead (mm) |
Full step (mm) |
86SE1876-460-TR15.875*xxx-150-01 | 76 | 1.8 | 6.0 | 4.5 | 15.875 | 2.54 3.175 5.08 6.35 12.7 25.4 |
0.0127 0.015875 0.0254 0.03175 0.0635 0.127 |
86SE18114-460-TR15.875*xxx-150-01 | 114 | 1.8 | 6.0 | 8.0 | 15.875 | 2.54 3.175 5.08 6.35 12.7 25.4 |
0.0127 0.015875 0.0254 0.03175 0.0635 0.127 |
