Product model：PEZ060-L2

Product name：Plantery Reducer

Specification range: 60-180
Cost-effective, light and easy to install
The gear quenching hardness reaches 62 degrees, and the tooth surface is ground
Can be equipped with any brand of servo and stepper motor
The surface is treated with baking paint to ensure that the appearance does not change color and rust

Online purchase →

Specification Dimension Accessory products Related products Download materials

Model	Ratio	Output Torque（Nm）	Match Motor
φ14
PEZ060-L2-9	9	27	53#Motor
PEZ060-L2-12	12	27	54#Motor
PEZ060-L2-15	15	27	55#Motor
PEZ060-L2-16	16	40	56#Motor
PEZ060-L2-20	20	40	57#Motor
PEZ060-L2-25	25	40	58#Motor
PEZ060-L2-28	28	40	59#Motor
PEZ060-L2-30	30	27	60#Motor
PEZ060-L2-35	35	40	61#Motor
PEZ060-L2-40	40	40	62#Motor
PEZ060-L2-50	50	40	63#Motor
PEZ060-L2-70	70	34	64#Motor
PEZ060-L2-100	100	16	65#Motor
57#Motor φ6.35
PEZ060-L2-9-57-6.35x31	9	27	57#
PEZ060-L2-12-57-6.35x31	12	27	57#
PEZ060-L2-15-57-6.35x31	15	27	57#
PEZ060-L2-16-57-6.35x31	16	40	57#
PEZ060-L2-20-57-6.35x31	20	40	57#
PEZ060-L2-25-57-6.35x31	25	40	57#
PEZ060-L2-28-57-6.35x31	28	40	57#
PEZ060-L2-30-57-6.35x31	30	27	57#
PEZ060-L2-35-57-6.35x31	35	40	57#
PEZ060-L2-40-57-6.35x31	40	40	57#
PEZ060-L2-50-57-6.35x31	50	40	57#
PEZ060-L2-70-57-6.35x31	70	34	57#
PEZ060-L2-100-57-6.35x31	100	16	57#
#57 φ8
PEZ060-L2-9-57-8x31	9	27	57#
PEZ060-L2-12-57-8x31	12	27	57#
PEZ060-L2-15-57-8x31	15	27	57#
PEZ060-L2-16-57-8x31	16	40	57#
PEZ060-L2-20-57-8x31	20	40	57#
PEZ060-L2-25-57-8x31	25	40	57#
PEZ060-L2-28-57-8x31	28	40	57#
PEZ060-L2-30-57-8x31	30	27	57#
PEZ060-L2-35-57-8x31	35	40	57#
PEZ060-L2-40-57-8x31	40	40	57#
PEZ060-L2-50-57-8x31	50	40	57#
PEZ060-L2-70-57-8x31	70	34	57#
PEZ060-L2-100-57-8x31	100	16	57#
60#Motor φ8
PEZ060-L2-9-60-8x31	9	27	60#
PEZ060-L2-12-60-8x31	12	27	60#
PEZ060-L2-15-60-8x31	15	27	60#
PEZ060-L2-16-60-8x31	16	40	60#
PEZ060-L2-20-60-8x31	20	40	60#
PEZ060-L2-25-60-8x31	25	40	60#
PEZ060-L2-28-60-8x31	28	40	60#
PEZ060-L2-30-60-8x31	30	27	60#
PEZ060-L2-35-60-8x31	35	40	60#
PEZ060-L2-40-60-8x31	40	40	60#
PEZ060-L2-50-60-8x31	50	40	60#
PEZ060-L2-70-60-8x31	70	34	60#
PEZ060-L2-100-60-8x31	100	16	60#
60#（φ10
PEZ060-L2-9-60-10x31	9	27	60#
PEZ060-L2-12-60-10x31	12	27	60#
PEZ060-L2-15-60-10x31	15	27	60#
PEZ060-L2-16-60-10x31	16	40	60#
PEZ060-L2-20-60-10x31	20	40	60#
PEZ060-L2-25-60-10x31	25	40	60#
PEZ060-L2-28-60-10x31	28	40	60#
PEZ060-L2-30-60-10x31	30	27	60#
PEZ060-L2-35-60-10x31	35	40	60#
PEZ060-L2-40-60-10x31	40	40	60#
PEZ060-L2-50-60-10x31	50	40	60#
PEZ060-L2-70-60-10x31	70	34	60#
PEZ060-L2-100-60-10x31	100	16	60#
