型号：PEZ090-L2

名称：Plantery Reducer

Specification range: 60-180
Cost-effective, light and easy to install
The gear quenching hardness reaches 62 degrees, and the tooth surface is ground
Can be equipped with any brand of servo and stepper motor
The surface is treated with baking paint to ensure that the appearance does not change color and rust

在线购买 →

Specification Dimension 配套相关下载

Model	Ratio	Rated Torque（Nm）	Match
80# φ19
PEZ090-L2-9	9	96	80#
PEZ090-L2-12	12	96	80#
PEZ090-L2-15	15	96	80#
PEZ090-L2-16	16	122	80#
PEZ090-L2-20	20	122	80#
PEZ090-L2-25	25	122	80#
PEZ090-L2-28	28	122	80#
PEZ090-L2-30	30	96	80#
PEZ090-L2-35	35	122	80#
PEZ090-L2-40	40	122	80#
PEZ090-L2-50	50	122	80#
PEZ090-L2-70	70	95	80#
PEZ090-L2-100	100	56	80#
86# φ12.7
PEZ090-L2-9-86-12.7x38	9	96	86#
PEZ090-L2-12-86-12.7x38	12	96	86#
PEZ090-L2-15-86-12.7x38	15	96	86#
PEZ090-L2-16-86-12.7x38	16	122	86#
PEZ090-L2-20-86-12.7x38	20	122	86#
PEZ090-L2-25-86-12.7x38	25	122	86#
PEZ090-L2-28-86-12.7x38	28	122	86#
PEZ090-L2-30-86-12.7x38	30	96	86#
PEZ090-L2-35-86-12.7x38	35	122	86#
PEZ090-L2-40-86-12.7x38	40	122	86#
PEZ090-L2-50-86-12.7x38	50	122	86#
PEZ090-L2-70-86-12.7x38	70	95	86#
PEZ090-L2-100-86-12.7x38	100	56	86#
86# φ14
PEZ090-L2-9-86-14x38	9	96	86#
PEZ090-L2-12-86-14x38	12	96	86#
PEZ090-L2-15-86-14x38	15	96	86#
PEZ090-L2-16-86-14x38	16	122	86#
PEZ090-L2-20-86-14x38	20	122	86#
PEZ090-L2-25-86-14x38	25	122	86#
PEZ090-L2-28-86-14x38	28	122	86#
PEZ090-L2-30-86-14x38	30	96	86#
PEZ090-L2-35-86-14x38	35	122	86#
PEZ090-L2-40-86-14x38	40	122	86#
PEZ090-L2-50-86-14x38	50	122	86#
PEZ090-L2-70-86-14x38	70	95	86#
PEZ090-L2-100-86-14x38	100	56	86#
86# φ16
PEZ090-L2-9-86-16x38	9	96	86#
PEZ090-L2-12-86-16x38	12	96	86#
PEZ090-L2-15-86-16x38	15	96	86#
PEZ090-L2-16-86-16x38	16	122	86#
PEZ090-L2-20-86-16x38	20	122	86#
PEZ090-L2-25-86-16x38	25	122	86#
PEZ090-L2-28-86-16x38	28	122	86#
PEZ090-L2-30-86-16x38	30	96	86#
PEZ090-L2-35-86-16x38	35	122	86#
PEZ090-L2-40-86-16x38	40	122	86#
PEZ090-L2-50-86-16x38	50	122	86#
PEZ090-L2-70-86-16x38	70	95	86#
PEZ090-L2-100-86-16x38	100	56	86#
